| 噴霧夾角 | 不同距離下（從噴嘴口算起）的理論覆蓋范圍（厘米）（D） | |||||||||||
| 5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 100 | |
| 5° | 0.4 | 0.9 | 1.3 | 1.8 | 2.2 | 2.6 | 3.5 | 4.4 | 5.2 | 6.1 | 7 | 8.7 |
| 10° | 0.9 | 1.8 | 2.6 | 3.5 | 4.4 | 5.3 | 7 | 8.8 | 10.5 | 12.3 | 14 | 17.5 |
| 15° | 1.3 | 2.6 | 4 | 5.3 | 6.6 | 7.9 | 10.5 | 13.2 | 15.8 | 18.4 | 21.1 | 26.3 |
| 20 ° | 1.8 | 3.5 | 5.3 | 7.1 | 8.8 | 10.6 | 14.1 | 17.6 | 21.2 | 24.7 | 28.2 | 35.3 |
| 25° | 2.2 | 4.4 | 6.7 | 8.9 | 11.1 | 13.3 | 17.7 | 22.2 | 26.6 | 31 | 35.5 | 44.3 |
| 30 ° | 2.7 | 5.4 | 8 | 10.7 | 13.4 | 16.1 | 21.4 | 26.8 | 32.2 | 37.5 | 42.9 | 53.6 |
| 35 ° | 3.2 | 6.3 | 9.5 | 12.6 | 15.8 | 18.9 | 25.2 | 31.5 | 37.8 | 44.1 | 50.5 | 63.1 |
| 40 ° | 3.6 | 73 | 10.9 | 14.6 | 18.2 | 21.8 | 29.1 | 36.4 | 43.7 | 51 | 58.2 | 72.8 |
| 45 ° | 4.1 | 8.3 | 12.4 | 16.6 | 20.7 | 24.9 | 33.1 | 41.4 | 49.7 | 58 | 66.3 | 82.8 |
| 50 ° | 4.7 | 9.3 | 14 | 18.7 | 23.3 | 28 | 37.3 | 46.6 | 56 | 65.3 | 74.6 | 93.3 |
| 55 ° | 5.2 | 10.4 | 15.6 | 20.8 | 26 | 31.2 | 41.7 | 52.1 | 62.5 | 72.9 | 83.3 | 10.4 |
| 60 ° | 5.8 | 11.6 | 17.3 | 23.1 | 28.9 | 34.6 | 46.2 | 57.7 | 69.3 | 80.8 | 92.4 | 11.5 |
| 65 ° | 6.4 | 12.7 | 19.1 | 25.5 | 28.9 | 38.2 | 51 | 63.7 | 76.5 | 89.2 | 102 | 127 |
| 70 ° | 7 | 14 | 21 | 28 | 35 | 42 | 56 | 70 | 84 | 98 | 112 | 140 |
| 75 ° | 7.7 | 15.4 | 23 | 30.7 | 38.4 | 46 | 61.4 | 76.7 | 92.1 | 107 | 123 | 153 |
| 80 ° | 8.4 | 16.8 | 25.2 | 33.6 | 42 | 50.4 | 67.1 | 83.9 | 101 | 118 | 134 | 168 |
| 85 ° | 9.2 | 18.3 | 27.5 | 36.7 | 45.8 | 55 | 73.6 | 91.6 | 110 | 128 | 147 | 183 |
| 90 ° | 10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 | 120 | 140 | 160 | 200 |
| 95 ° | 10.9 | 21.8 | 32.7 | 43.7 | 54.6 | 65.5 | 87.3 | 109 | 131 | 153 | 175 | 218 |
| 100 ° | 11.9 | 23.8 | 35.8 | 47.7 | 59.6 | 71.5 | 95.3 | 119 | 143 | 167 | 191 | 238 |
| 110 ° | 14.3 | 28.6 | 42.9 | 57.1 | 71.4 | 85.7 | 114 | 143 | 171 | 200 | 229 | 286 |
| 120 ° | 17.3 | 34.6 | 52 | 69.3 | 86.6 | 104 | 139 | 173 | 208 | 243 | ||
| 130 ° | 21.5 | 42.9 | 64.3 | 85.8 | 107 | 129 | 172 | 215 | 257 | |||
| 140 ° | 27.5 | 55 | 82.4 | 110 | 137 | 165 | 220 | 275 | ||||
| 150 ° | 37.3 | 74.6 | 112 | 149 | 187 | 224 | 299 | |||||
| 160 ° | 56.7 | 113 | 170 | 227 | 284 | |||||||
| 170° | 114 | 229 | ||||||||||
